Application Cases

Tea Grinding Experiment

2014-11-25


Backgrounds: Ground by vertical planetary ball mill matched with nylon pots and zirconia balls. Grinding time: one hour. Granularity of output powder meets customer’s request 100%.

Applied Machine: Tencan Vertical Planetary Ball Mill Model No.XQM-4

1. Description
1) Applied Field: Food Industry.
2) Materials: Green Tea
3) Feed Size: 1mm.
4) Quantity of Feed: 500g
5) Property of Material: Small leaf of tea
6) Customer’s Request: Under 50μm.
7) Subsequent Analysis: Particle Size Test


 ⇒
                 Before Grinding                                             After Grinding

2.Solution:
1) Equipment Selection: Vertical Planetary Ball Mill Model XQM-4.
2) Accessories: Nylon Pots and Zirconia Balls.
3) Running Parameter Setting: Rotation Speed: 500rpm, Positive and Negative Reciprocal Operation after 30-minute running.
4) Grinding Time: One Hours
5) Grinding Result: 100%<50μm
6) Note: Material has to be dried completely before grinding
6) Conclusion: Planetary Ball Mill Model XQM-4 can be used to grind green tea.





3. Application Fields: Planetary ball mill model No.XQM-4 can be used to grind green tea.
